Aluminium window and door system · A65
A65 65mm thermally broken aluminium hinged-door system.
A65 is a thermally broken hinged-door system with 65.4 mm and 103.5 mm frame options. The reference hardware set uses IDH-G02 hinges and the IDL020341 lock, with gasketed frame-to-leaf junctions. Single-leaf, double-leaf and reinforced-mullion layouts are released against the opening schedule.
Construction and configuration
- A65 (65.4 mm) and A103 (103.5 mm) frame options
- Gasketed hinge side and closing perimeter
- Flush frame and door-leaf faces
- IDH-G02 hinge hardware with IDL020341 lock system
- 6063-T5 aluminum alloy with PPG powder coating
- PA66GF25 polyamide thermal barriers
- Three sealing levels with EPDM gaskets
- Optional reinforced mullion for extra-large openings
- Single-leaf and double-leaf configurations
Technical specifications.
| Frame Depth (A65) | 65.4 mm |
|---|---|
| Frame Depth (A103) | 103.5 mm |
| Minimum Interface Width (A65) | ≥ 75 mm |
| Minimum Interface Width (A103) | ≥ 115.5 mm |
| Hinge Set | IDH-G02 |
| Lock Set | IDL020341 |
| Reference Finish | PPG Powder Coating |
Catalogue dimensions describe the reference configuration. Confirm the infill, hardware, opening limits and released bill of materials before ordering.
Product FAQ
Technical questions.
Reference answers for early system selection. Final dimensions, components and performance are fixed in the project-specific technical package.
What is the frame depth of the A65 Hinged Door?
A65 Hinged Door has a listed frame depth of 65.4 mm. Confirm the infill, sash or leaf limits and hardware against the current technical data sheet and opening schedule.
Which materials are listed for the A65 Hinged Door?
The reference build lists 6063-T5 aluminium, PA66GF25 polyamide thermal barriers and EPDM gaskets. The released bill of materials remains project-specific.
Can a fabricator order the A65 Hinged Door as a production kit?
Yes. PINDÉ checks the opening schedule, opening type, glazing, hardware and destination requirements. Supply can include a system kit, machined profiles or a glass-free CKD kit.
